Case Study 4

A company is experiencing a noticeable decrease in performance when accessing data on their Dell EMC Isilon cluster. The cluster hosts Microsoft Windows home directories and general purpose file shares. In addition, a file pool policy moves data that has not been modified in six months to an achieve tier. The administrator wants your assistance in understanding the reason for the slow data access. The number of users accessing the cluster has not changed.

The administrator has shared the following baseline metrics. The outputs were captured from a performance- acceptable time frame.

Trace route shows:

-3 hops between clients and the cluster

-Average latency is 3 ms

Iperf shows:

-940 Mb/s average bandwidth

-005 ms average jitter

Netstat on the local network shows:

-05% average re-transmission rate

Hostcache list:

-20 ms average roundtrip time across all clients

The administrator shows you the following output from the netstat command:

32366653 data packets (35556615947 bytes)

8010 data packets (9525723 bytes) re-transmitted

Based on the output, what information should be provided to the administrator?

An administrator wants to increase network throughput for individual UNIX clients when accessing files on a Dell EMC Isilon Gen 6 cluster. The administrator has configured node interfaces to use LACP and has seen no increase in performance.

Why is there no increase in client-to-cluster network performance?

Which Dell EMC tool allows the auditing of user access and anti-virus scanning on an Isilon cluster?

A company wants to purchase four new Dell EMC Isilon H500 nodes to add their current Gen 5 cluster. Which internal requirements are needed?

A Microsoft Windows administrator has an environment that includes a 4-node Dell EMC Isilon H500 cluster with one subnet and two pools. The administrator will use SMBv3 in all their clients. One pool is for production using 10gige- 1 and 10gige-2 ports from each node. The other pool is for management using mgmt-1 from each node.

One of the concerns is the network throughput and how the administrator can get more than 10GbE throughput on the production pool on each node. Which recommendation should be provided?

A Dell EMC Isilon cluster replicates critical production data and long-term archive data from the data center to a target cluster. The source cluster runs OneFS 8.1.1 and the target cluster runs OneFS 7.2. OneFS will not be upgraded on the target cluster.

When the archived data on the source cluster is replicated to the target cluster, the capacity consumption on the source cluster far exceeds what is expected. What is the reason for the increase in capacity consumption on the cluster?

A company has a medical application that generates a large number of media files. The file count is well over one billion and is stored on a Dell EMC Isilon 8-node NL410 cluster. Currently, each node is connected to the network using two 10GbE connections. The Linux-based application does not require high bandwidth; however, it is latency sensitive. Additionally, the Linux hosts are connected to the cluster over NFSv3. The application generates approximately 10,000 files every 10 minutes.

For the past four years, the cluster has been growing at a rate of one additional node per year. The company is running out of free ports on their redundant network switches. They want to know what can be done to ensure continuous availability. They do not want to invest in upgrading the network infrastructure. In addition, the company needs to reduce the number of consumed interface ports on the switches.

Which recommendation should be provided?

A Dell EMC Isilon administrator has a 6-node X400 cluster. As the hardware is approaching end of service life, the administrator has planned for a technical refresh by replacing the 6-node X400 cluster with a 4-node H500 cluster.

The new 4-node H500 is added to the existing cluster and a SmartPools trial license is activated for data migration. The default location for the data and snapshots is changed in the default file pool policy from an X400 node pool to a H500 node pool. The SmartPool job is then run manually.

After the SmartPool job is finished, the X400 node pool still consumes approximately 10% of the storage.

What is a possible reason for this issue?

The :”nfs2” file system has been experiencing delays that have been impacting the entire Dell EMC Isilon cluster. Neither Snapshots nor SyncIQ is configured for these directories. Use the “Launch Simulator” button to verify the SSD strategy. Note: It is necessary to ‘close’ (x) the simulator window to answer the question.

Based on your findings, which operation should be performed to address the delays?

Case Study 1

A company has several independent business units that operate globally. The company has consolidated its IT infrastructure services and operations. Common infrastructural services which include IPAM, DNS, NTP, DHCP, and SMTP have been consolidated. The company has complimented its infrastructure development by investing in Dell EMC Isilon clusters to host its user’s home and group directories and for compliance archival purposes required by individual business units.

The IT operations are located in India and the United States with its primary data center facilities co-located between New York and Texas. The company has a total of 60 AD forests:

1 main domain

55 domains have one-way trust relationships with the main domain

An additional 4 domains do not have any trust relationship with no future plans of establishing trust relationships with the other domains.

Users of different AD domains use different FQDN to access their corresponding file services. Additionally, the company does not plan to consolidate the AD domains and each domain uses a different IP subnet. The users of the domains with no trust relationships have a compliance archival requirement. The company wants to all data to be replicated between New York and Texas.

How many tenant Access zones will be required?
