The label on the cable indicates two parts: “M91A-01:01” and “U61A-01:09”. The first part of the label “M91A” refers to a specific type of equipment as per the exhibit. According to the exhibit, “M9” corresponds to “MDS 9xxx”, which is a Cisco Multilayer Director Switch. The second part of the label, “U61A”, does not directly match any category in the provided list; however, it seems to be an internal reference that could be related to user-specific configurations or locations.

Since we are looking for the target equipment type and not where it was mistakenly connected, we focus on the first part of the cable label. The numbers following “M91A” indicate slot and port information. Therefore, based on this labeling system and referring to the exhibit provided, which lists various EMC and Cisco equipment types along with their corresponding codes (like AP for APIC Appliance or CN for Cust. Network), we can deduce that “M91A” stands for “MDS 9xxx”. The subsequent numbers “-01:01” suggest Slot 1, Port 1.

Identify the Issue: Heavy network utilization during video streaming indicates that multicast traffic is not being efficiently managed1.

Understand Multicast Traffic: Multicast applications use a single stream of data to deliver content to multiple recipients, which can cause network congestion if not handled properly1.

Recognize IGMP’s Role: Internet Group Management Protocol (IGMP) is used to manage multicast group memberships and is essential for optimizing multicast traffic on a network1.

Implement IGMP: Enabling IGMP allows the network to efficiently distribute multicast traffic only to hosts that have explicitly requested it, reducing unnecessary network load1.

Review ACI Fabric Topology: The ACI fabric topology is based on a spine-leaf architecture, which is a scalable, two-layer network topology composed of spine switches and leaf switches1.

Understand Spine-Leaf Benefits: This topology provides high-bandwidth connectivity between leaf switches and spine switches, allowing for efficient data flow across the network1.

Recognize ACI Fabric Design: In an ACI fabric, each leaf switch connects to every spine switch, creating a non-blocking, high-throughput network that supports east-west traffic patterns typical in modern data centers1.

Reference Official Documentation: The Official Dell VxBlock Deploy Achievement document would align with Cisco’s guidelines on ACI fabric, which specify the spine-leaf topology as the standard for ACI deployments1.
